Outdoor P4.81 Energy saving LED screen cabinet 500*1000mm and 1000x1000mm
  • ONLYLED-XT-ELITE
  • CHINA
  • 1000pcs /month
  • 1000pcs

Our P4.81 outdoor LED cabinet delivers outstanding brightness and clarity, even under direct sunlight. Engineered for durability and performance, the 5001000mm and 10001000mm aluminum LED cabinets fea

Product details

Our P4.81 outdoor LED cabinet delivers outstanding brightness and clarity, even under direct sunlight. Engineered for durability and performance, the 500×1000mm and 1000×1000mm aluminum LED cabinets feature IP66 waterproof modules (250×500mm), designed for front or rear maintenance. This modular solution is ideal for high-impact outdoor LED digital billboards, corner-wrapped LED displays, and architectural signage projects where performance, reliability, and flexibility are critical.


1. Key Features – P4.81 Outdoor LED Display Cabinet

  • High Brightness: Delivers up to 7,000 nits using premium SMD 3-in-1 LED lamps, ensuring vivid visuals and excellent readability in daylight or direct sun exposure—ideal for outdoor advertising LED screens.

  • Wide Viewing Angle: Offers a 110° horizontal viewing angle, providing consistent color and image sharpness across large public viewing zones.

  • Rugged & Weatherproof: Crafted with rust-proof aluminum cabinets and IP66-rated waterproof LED modules, this solution excels in harsh outdoor environments, from rain to dust and high heat.

  • Flexible Cabinet Sizes: Available in both 500×1000mm and 1000×1000mm, suitable for scalable digital signage systems, LED video walls, or large-format LED billboards.

  • Supports 90° Corner Installation: Perfect for 3D naked-eye LED displays, L-shaped LED video walls, building wraps, and edge-to-edge corner LED screen installations.

  • Versatile Mounting Options: Compatible with wall-mounted, roof-mounted, pole-mounted, mobile trailer displays, or double-sided billboard configurations.

  • Energy Efficient: Powered by common cathode LED technology, reducing power consumption, heat generation, and long-term operating costs.

  • Quick Maintenance: Modular cabinet design supports front-access and rear-access servicing, making it ideal for low-maintenance LED signage in high-traffic zones.

  • Smart Control System: Integrated with a built-in receiving card, color and brightness auto-calibration, and remote management via Wi-Fi, 4G, or cloud-based LED control systems.


2. Recommended Applications

ONLY LED’s P4.81 high-brightness outdoor LED cabinet is a powerful and versatile solution for a wide range of outdoor digital display projects. Designed to meet the evolving demands of modern LED signage, its durable structure, pixel density, and corner-friendly configuration make it ideal for:

  • Large-format LED advertising billboards

  • 3D corner LED displays with naked-eye visual effects

  • Out-of-home (OOH) LED advertising networks

  • Digital signage for commercial buildings and retail storefronts

  • Curved or right-angle LED wall installations on building corners

  • High-resolution outdoor LED video walls

  • Smart LED signage for transportation hubs, sports venues, and public information systems

  • Custom-shaped LED display designs, including L-shapes and U-wraps for architectural integration

Backed by a 3-to-5 year warranty, this product is a reliable, energy-efficient, and high-contrast LED screen solution for any demanding outdoor environment.


3. Product parameters


MODEL NUMBERXTE-PH4.81-OC
LED cabinet Size1000*1000 mm / 1000*500mm
Pixel  Pitch 4.81mm
LEDsSMD1921 / super-brigthness and golden wire LEDs
Weight  /㎡32KGS /㎡
Density of pixel 43,264 Pixel/㎡
Resolution/Cabinet208pixel*208pixel  / 208 pixel*104pixel
viewing angle/horizontal 110°
Viewing angle/Vertical 90°
Average power/sqm (W)185
Max power/sqm (W)560
Driving Method 1/4 Scan
Refresh rate ≥3840HZ
Brightness≥7,000 cds/㎡
Working environmentOutdoor
WaterproofIP66
Grey scale/display color 65536/display 16.7M
frame frequency ≥60HZ
Brightness adjustmentManual R.G.B each color 256,automatic 8 grades are adjustable
Control system Colorlight and Novastar
System Operation PlatformWindows
Average no Failure time ≥10000hrs
Lifetime of Led  ≥100000hrs
Malfunction do rate <0.0001
Working Voltage 120V to 240V AC
Earth leakage current <0.01mA
working / Storage temperature    working -30℃~60℃    storage -40℃~85℃
