12‘ x 24‘ outdoor LED scoreboard, P6.35mm, 10,500 nits. Includes scoring software for basketball, football, volleyball. Factory direct, DDP to USA, 6-year warranty.
Product details
12' x 24' Outdoor LED Scoreboard
P6.35mm, 10,500 nits, single-sided. Scoring software included. Factory direct to USA.
Specifications
| Parameter | Value |
|---|---|
| Display size | 12 ft x 24 ft (3.7 m x 7.3 m) |
| Display area | 288 sq ft (26.8 m²) |
| Faces | Single-sided |
| Pixel pitch | 6.35 mm |
| LED type | SMD2727, golden wire |
| Resolution | 576 x 1152 pixels |
| Brightness | 10,500 nits |
| Refresh rate | 3,000 Hz minimum |
| Cabinet | 3 x 4 ft (914 x 1219 mm), die-cast aluminum, 70 lbs |
| Protection | IP66 front and rear |
| Control system | Colorlight, HDMI sender, auto-brightness dimmer box |
| Scoring software | Basketball, volleyball, football, futsal, handball, water polo, ice hockey |
| Power input | 100-240V AC, 50/60 Hz |
| Max power draw | 21,600 W (196 A @ 110 V) |
| Avg power draw | 6,480 W (59 A @ 110 V) |
| Warranty | 6 years |
| Certifications | ETL, CE, FCC, RoHS, USA Patent US-11871528-B1 |
Scoreboard Applications
LED Cabinet
Scoring Software
The order includes PC scoring control software (BG-PC-CTL) and a playout interface (BG-PC-PLAY). The scorekeeper runs scoring and timing from a laptop at the scorer's table, connected by USB and HDMI. A software license dongle is included. Team names, fonts, colors and scoreboard layout can be customized.
What Ships With the Order
LED cabinets, HDMI sender box, outdoor dimmer box with light sensor, scoring software with license dongle, 5% spare LED modules, spare power/control box, plywood packing crates, and DDP ocean freight door-to-door to your address in the USA. Customs, duties and last-mile trucking are included.
Request Scoreboard Pricing
Send your venue size, sport and delivery address. We reply with layout and DDP pricing within one business day.
