10x20ft Double faces Outdoor LED Billboard – 9.52mm, 10,000 Nits, Front Service, Energy Saving .High-brightness 10x20ft outdoor LED display with 9.52mm pixel pitch and 10,000 nits brightness. Two face

Product details

10x20ft Double faces Outdoor LED Billboard – 9.52mm, 10,000 Nits, Front Service, Energy Saving .High-brightness 10x20ft outdoor LED display with 9.52mm pixel pitch and 10,000 nits brightness. Two faces and Features front-service aluminum cabinet, common cathode power solution, CE EMC, ETL certified. Ideal for digital advertising. Backed by a 6-year warranty.


                                  10' x 20 ' Double-faces Outdoor LED billboard Display Specifications

CategorySpecification
Display Size10 ft × 20 ft * 2faces
Total Display Area400 sq ft
Number of Faces2
Physical Resolution (H × W)320 × 640 pixels each face of billboard
Total Pixel Count409,600 pixels
Pixel Pitch9.52 mm
Brightness10,000 nits
Warranty6 Years
                                                             Electrical Requirements (Two faces of LED billbaords)
Working Voltage120V to 240V AC
Maximum Power Draw205 Amps @ 120V AC
Average Power Draw70 Amps @ 120V AC


ONLY LED Billboard Display Cabinets – 2'x4' and 3'x4'

ONLY LED DISPLAY’s outdoor LED billboard cabinets are engineered for high-brightness, energy-efficient performance in all weather conditions. Available in 2'x4' and 3'x4' sizes, they are ideal for large-format signage such as pole signs, wall-mounted LED displays, and double-sided billboards.


Key Features:

  • Front-Serviceable Modular Design – Easy installation and maintenance

  • Die-Cast Aluminum Housing – Strong, lightweight, with excellent heat dissipation

  • Common Cathode Power System – Low heat, energy-saving design

  • Ultra-High Brightness – Up to 10,000 nits for clear daytime visibility

  • Slim & Lightweight – Ideal for space-limited and double-sided installations

  • CertificationsCE EMC/LVD, FCC, ETL, RoHS

  • U.S. Patent No. US11871528B1 – Protected structure and power design

  • 6-Year Warranty – Reliable, long-term outdoor performance


                                                 2'x4' and 3'x4' LED Panel Main Specifications

MODEL NUMBER

 UP-PH9.52-CDL4  / UP-PH9.52-CDL6

LED cabinet Size2'x 4'  / 3 'x4'
Pixel  Pitch 9.52mm
LEDsSMD2727   Golden wire SMD
Weight51Lbs / 70 Lbs
Density of pixel 11022pixel/㎡
Resolution/Cabinet64pixel*128pixel  / 96 pixel*128pixel
viewing angle/horizontal 110°
Viewing angle/Vertical 90°
Average power/Panel (W)160W  /  225W
Max power/Panel (W)480W / 642 W
Driving Method 1/4  Scan
Refresh rate ≥3000HZ
Brightness≥10,000cds/㎡
Working environmentOutdoor
WaterproofIP66
Grey scale/display color 65536/display 16.7M
frame frequency ≥60HZ
Brightness adjustmentManual R.G.B each color 256,automatic 8 grades are adjustable
Control system Colorlight and Novastar
System Operation PlatformWindows
Average no Failure time ≥10000hrs
Lifetime of Led  ≥100000hrs
Malfunction do rate <0.0001
Working Voltage 120V to 240V AC
Earth leakage current <0.01mA
working / Storage temperature Working -30℃~60℃    Storage -40℃~85℃
CertificatesCE EMC LVD FCC ETL /UPSTO Patent No. US11871528B1


Why Choose Digital LED Billboards?

Digital LED billboards offer unmatched flexibility and impact compared to traditional static signage. With vibrant full-color visuals, dynamic content scheduling, and real-time updates, they allow you to run multiple ads from one screen — increasing engagement and revenue. Perfect for roadside advertising, retail promotions, event announcements, and community messaging, LED billboards deliver visibility 24/7, in any weather.


Benefits of Digital LED Billboards:

  • Display multiple rotating ads

  • Remotely manage content anytime

  • Ultra-bright and readable in daylight

  • Cost-effective over time with no printing

  • Boosts brand visibility and ROI


Why Choose ONLY LED’s 2'x4' and 3'x4' LED Billboard Cabinets?

ONLY LED’s 2'x4' and 3'x4' LED display cabinets are engineered for maximum durability, energy efficiency, and low maintenance — ideal for outdoor digital billboard applications.

Key Advantages:

  • Premium Materials – Die-cast aluminum housing ensures excellent heat dissipation, rust resistance, and long-term structural strength

  • Weatherproof & Rugged – Built for harsh outdoor environments with IP-rated protection and front-service access

  • Energy-Saving Technology – Common cathode power design reduces heat and lowers electricity bills

  • Extreme Brightness – Up to 10,000 nits for perfect visibility even under strong sunlight

  • Slim & Lightweight Design – Ideal for wall-mounted and double-sided billboard installations

  • Certified & Patented – CE EMC/LVD, ETL, FCC, RoHS compliant, with U.S. Patent No. US11871528B1

  • 6-Year Warranty – Long-term peace of mind backed by factory-supported warranty and proven reliability


What ONLY LED Can Do for You

ONLY LED DISPLAY is more than just a supplier — we are your complete LED display partner from factory to field. Here’s what we can do to support your LED billboard project:

1. We Are a Direct LED Display Factory
ONLY LED is a 100% true LED display manufacturer. No middlemen. We control production, quality, and delivery — offering you factory pricing, fast lead times, and full customization.

2. We Supply Cabinets with Structural Drawings
We provide standard cabinet sizes such as 2'x4' and 3'x4', along with detailed structural drawings to assist with billboard design, engineering, and permit applications in your local area.

3. We Offer Software Training
We provide complete training on LED control software and display management systems so your team can confidently operate and schedule content on your LED billboard.

4. We Can Send Engineers for On-Site Support
Our experienced technicians are available for overseas installation support, including LED cabinet assembly, screen alignment, wiring, and system configuration.

5. We Customize to Fit Your Project
From cabinet size and layout to power systems and branding, we offer full customization and OEM/ODM service to meet your specific requirements.


Why Work With ONLY LED?

  • Over 15 years of LED manufacturing experience

  • Energy-efficient, ultra-bright LED displays (up to 10,000 nits)

  • CE EMC, LVD, ETL, FCC, RoHS certified

  • Protected by U.S. Patent No. US11871528B1

  • 6-year product warranty

  • Professional and responsive after-sales service

  • Fast production and worldwide delivery


ONLY LED DISPLAY – Smarter. Brighter. Greener.
Your reliable partner for LED billboard displays and total project support.
